AT83 gray colour aluminum alloy body double acting pneumatic actuator

Ask Lasest Price
Brand Name :	OEM
Model Number :	DA,SR
Certification :	CE,ATEX,ISO,SGS
Price :	10
Payment Terms :	T/T, Western Union
Supply Ability :	5000 sets per month
Delivery Time :	3-15days

Add to Cart

Product Details
Company Profile

AT83 gray colour aluminum alloy body double acting pneumatic actuator

AT83 gray colour aluminum alloy body double acting pneumatic actuator

Pneumatic Actuator

Material	Extruded Aluminum alloy
Rotary Angle	0~90 degree
Structure	rack and pinion rotary actuator
Working Pressure	2~8bar
Surface Treatment	hard anodizing
Working Temperature	Normal Temperature: -20ºC(-4°F) ~ 80ºC (+176°F); High Temperature: -15ºC(+5°F) ~ 150ºC (+302°F); Low Temperature: -40ºC(-104°F) ~ 80ºC (+176°F).
Connection	NAMUR, ISO5211 and DIN3337
Application	ball valve, butterfly valve, and rotary machine
Cup Color	grey, black, sky blue, dark blue, red, orange

Main Features

Dual piston rack and pinion design for compact construction,symmetric mounting positon,high-cycle life and fast opeation,reverse rotaton can be accomplished in the field by simply inverting the pistons.
Multiple bearings and guides on racks and pistons,low friction,high cycle life and prevent shaft blowout.
Modular preloaded spring cartridge design.with coated spring for simply versatile range,greater safely and corroson resistance, longer cycle life.
Fully machined teech on piston and pinion for accurate low backlash rack and pinion engagement,maximum efficiency.
Stainless steel fasteners for long term corrosion resistance.
Fullconformance to the latest specification;ISO5211.DIN3337 and Namur or product interchange ability and easy mounting of solenoids, limit switches and other accesories.

Pneumatic Actuator Dimension

AT83 gray colour aluminum alloy body double acting pneumatic actuator

Model

H×I

Air connection

XMO32

110

50×25

Æ36

M5×7.5

G1/8"

XM040

122

80×30

Æ50

Æ36

M6×10

M5×7.5

NAMUR G1/4"

XM052

147

80×30

Æ50

Æ36

M6×10

M5×7.5

NAMUR G1/4"

XM063

172

80×30

Æ70

Æ50

M8×13

M6×10

NAMUR G1/4"

XM075

184

100

80×30

Æ70

Æ50

M8×13

M6×10

NAMUR G1/4"

XM083

204

109

103

80×30

Æ70

Æ50

M8×13

M6×10

NAMUR G1/4"

XM092

262

117

109

80×30

Æ70

Æ50

M8×13

M6×10

NAMUR G1/4"

XM105

268

133

121

80×30

Æ102

Æ70

M10×16

M8×13

NAMUR G1/4"

XM125

301

155

143

80×30

Æ102

Æ70

M10×16

M8×13

NAMUR G1/4"

XM140

394

173

152

80×30

Æ125

Æ102

M12×20

M10×16

NAMUR G1/4"

XM160

458

198

174

80×30

Æ125

Æ102

M12×20

M10×16

NAMUR G1/4"

XM190

528

232

206

130×30

Æ140

M16×24

NAMUR G1/4"

XM210

532

257

226

130×30

Æ140

M16×24

NAMUR G1/4"

XM240

660

291

260

130×30

Æ165

M20×25

NAMUR G1/4"

XM270

740

330

294

130×30

Æ165

M20×25

NAMUR G1/2"

XM300

798

354

336

130×30

Æ165

M20×25

NAMUR G1/2"

XM350

880

408

385

130×30

Æ165

M20×25

NAMUR G1/2"

XM400

950

464

516

130×30

Æ254

Æ165

8-M16×25

M20×25

NAMUR G1/2"

Product Application

AT series Pneumatic Actuator is made of dual pistons driven by racks and pinions. There are two models. One is Dual Acting model, and the other is Spring Return model, which can suit various flammable, corrosive, dusty, strong magnetic field, radiation, vibration corrosive environment indoor or outdoor.

Auto-control in the field of electric power, petrochemical, metallurgy, petroleum, gas, town, construction, drainage, chemical industry, oil refining, mining, power plant, metallurgy, architecture, medicine, food, gas, scientific research, etc.
